For bulk plating
of the small articles and samplings the barrels plating has been
considered the most economical method because of low labour cost and elimination of racking and rack
maintenance.
A complete range of
manual and automatic plating barrels as small as 5” x 3.5” A/F to as
large as 48” x 18” A/F and also custom built.
|
|
|
|
|
PORTABLE
PLATING BARRELS : Miniature Barrels
|
|
This
fully immersed polypropylene / perspex
barrel is suitable for 0.5 to 2 Kg. plating range. The barrel is
powered by geared motor, 12 volts D.C. (with power drive) or A.C.
geared motor. The tank of PP/PVC / Perspex fitted with Bus-Bars &
Danglers. Optional : Heater, Air Agitation, Cathode Movement, Filter,
Rectifier etc.
|
|
|
|
|
|
|
STANDARD
RANGES:
|
|
Barrel Size
|
Approx. Capacity
|
Tank Size
|
|
6.5” x 3.5” A/F
|
upto 0.5 kg.
|
10” x 10” x 9”
|
|
7” x 4” A/F
|
upto 1 kg.
|
12” x 11” x 9”
|
|
7” x 5” A/F
|
upto 2 kg.
|
12” x 12” x 9”
|
|
|
|
|
|
|
Medium
BARRELS:
Medium portable barrels are in hexagonal design for two sizes viz: 3 to 5 kgs and 7
to 10 kgs. Octagonal Barrels are in bigger
sizes from 15 kgs. onwards
made of Acrylic, PP or CPVC, for most applications. Powered by low
voltage DC geared motor (supplied with Power Drive) or AC motor single
or three phase, geared or gearbox driven through V-belt, operated
single (having two or four cathode contacts) or two operators or by
hoist/transport mechanism. Mechanical disengaging arrangement for
loading and unloading.
STANDARD
SIZES:
11” x 7”, 12” x 8”, 18” x 10”, 24” x 10”A/F or bigger sizes. Suitably
lined-tank from 2’ x 1.5’ x 1.5’ onwards can also be made for these
Barrels with Standard filltings.
|
|
|
|
|
|
SUBMERSIBLE
PLATING BARRELS:
This is fully submerged barrel for the bulk, rapid and efficient
handling of small articles. The unit is equipped with Perspex/PP/CPVC
barrel powered by three phase motor directly coupled to gear box and
suitably lined tank and fittings, PVC coated / sleeved, danglers, hand
operated pinion sector mechanism and emptied through hopper into a
bucket. Standard sizes :
|
